Technical Highlights

• High-End 1G/2.5G Audiophile Ethernet Switch with Integrated OCXO Master Clock

• CNC-Machined Solid Billet Aluminum Chassis [Silver / Black]

• All-in-One Architecture: Segregated 2.5G Main Switching Zone + 1G Isolated Audio Zone + Ultra-Low Phase Noise Clock

• Built-in Dual Single-Mode Optical Fiber Links for Zone Isolation (Optical-Electrical Separation)

• AC Inlet: High-Quality IEC with Power Switch and Fuse Protection

• AC Noise Filtering: UK RIFA RFI Suppression Capacitors and EMI Filter

• Dual 50VA Audio-Grade Toroidal Transformers (Multicomp NORATEL Series)

• 18 Sets of Multi-Stage uV-Class Linear Power Regulation, Fully Linear , LDO

• Premium Vishay BC056 12x 4700uF Reservoir Capacitors

• SC-CUT Dual Thermostatically-Controlled OCXO with High-end PLL Synthesizer

• Ultra-Low Phase Noise: Better than -110 dBc/Hz

• Reclocking of Internal Network Zones & External Clock Output

• Master Clock Functionality: Two 10MHz BNC Outputs (50Ω-75Ω, Squarewave)

• Integrated Passive Thermal Management via Chassis Heatsinking

• Isolated Ground Terminal with Ground Lift Switch for Ground Loop Management

Connectivity

• 4 × RJ-45 2.5G Gigabit Ethernet Ports (Red Zone)

• 2 × RJ-45 Isolated 1G Gigabit Port (Green Zone - Audio)

• 1 × SFP Port for Fiber Input (Red Zone)

• 1 × SFP Port for Fiber Input (Green Zone - Audio)

• 2 × 10MHz Master Clock Outputs (BNC, 50Ω - 75Ω)

OCXO & Master Clock

• Oscillator Type: SC-CUT OCXO (Dual, Independent Chambers)

• Phase Noise: Better than -110 dBc/Hz @ 1Hz Offset

• Clock Distribution: Internal Zones & External Devices

• External Clock Output: 2 x 10MHz BNC, 50Ω-75Ω  (Square Wave)

What’s in the Box

• SW-10PRO Audiophile Ethernet Switch

• Generic Power Cord

• OCXO Phase Noise and Alan Deviation Test Report

Dimensions & Weight

• Dimensions: 400mm (W) × 55mm (H) × 260mm (D)

• Weight: 5.5 kg

Warranty

• 12 months

Product Link: https://www.vinshine.audio/vinshine-x-sw-10pro

Quick Start Guide: link

Recommended Fiber Optics / SFP Modules

• Finisar FTLF1318P3BTL SFP Module
  Datasheet

• FS.com Single-mode OS2 Fiber Optic Cable (Inverted/Crossed)
  Product Link

Important Note:

The SW-10PRO is a high-performance Ethernet network switch designed to complement —not replace— your existing modem and router. It requires integration with a router to function as part of your home network. If you're unsure about setup or compatibility, please don't hesitate to contact us—we're here to help.

Contact Us: sales@vinshineaudio.com

The SW-10PRO is a special collaboration model co-developed by Vinshine Audio and LHY Audio, built upon the foundation of the AS-8PRO with several critical enhancements for elevated performance:


• Upgraded OCXO: Equipped with an all-new military-grade SC-CUT OCXO featuring ultra-low phase noise better than -110 dBc/Hz at 1Hz offset, offering superior timing accuracy.

• Enhanced Power Supply: Utilizes 12 × Vishay BC056 high-grade reservoir capacitors (vs. 6 on AS-8PRO), delivering greater current stability and lower noise floor.

• Superior Clock Architecture: Features a top-tier PLL clock synthesizer that distributes ultra-precise 10MHz signals to both the 1G and 2.5G network zones.

• Dual Master Clock Outputs: The SW-10PRO doubles as a high-end 10MHz Master Clock generator, equipped with two precision 50Ω BNC outputs. This allows it to simultaneously synchronize multiple high-end components—such as streamers, DACs, or reclockers—ensuring system-wide timing coherence, reduced jitter, and a significant uplift in overall sonic transparency and imaging stability. (AS-8PRO offers 1 in, 1 out.)

• Exclusive Design: Features Vinshine Audio embossed branding on a CNC-milled aluminum billet chassis

• Test Certification Included: Each unit is shipped with a serialized, traceable OCXO Phase Noise and Allan Deviation Test Report, assuring measured performance and quality
